Electrical Specifications
Frequency Range	2400MHz-2500MHz
Gain	2dBi
VSWR	＜1.92
Polarization	Linear. Vertical
Max power rating	50W
Impedance	50Ω
Mechanical Specifications
Connector Type	SMA
Coaxial Cable Type	RG-178
Radiator Material	Copper
Working Temperature	-25℃-+75℃
Humidity	90% @ 25℃
Dimensions	OD:10.0*108.5mm
