Product Name	Pole Mount Antenna
Description	Applications:  450MHz band  SCDMA450 Cellular Systems  Multi-point Application  Point-2-point Application  Client Antenna Features:  Superior Performance  Small Size, Low Profile  Lightweight ABS Radome  Outoor used  Integral N-Female Connector
Electrical Specifications
Frequency Range–MHz	420-470
Bandwidth-MHz	20
Gain-dBi	6.5
Horizontal Beamwidth -°	120
Vertical Beamwidth -°	85
F/B ratio-dB	≥15
VSWR	≤1.5
Input Impedance -Ω	50
Polarization	Vertical
Maximum Power -W	100
Connector	N Female
Mechanical Specifications
Dimensions-mm	240×230×50
Weight-kg	0.35
